| Size/Weight |
| Dimensions |
Width |
1,336 mm [52-5/8″] |
1,326 mm [52-3/16″] |
| Height |
145 mm [5-11/16″] (with music rest: 328 mm [12-15/16″]) |
129 mm [5-1/16″] (with music rest: 327 mm [12-7/8″]) |
| Depth |
376 mm [14-13/16″] (with music rest: 403 mm [15-7/8″]) |
272 mm [10-11/16″] (with music rest: 362 mm [14-1/4″]) |
| Weight |
Weight |
22.0 kg [48 lb, 8 oz] |
11.5 kg [25 lb, 6 oz] |
| Dimensions (with optional stand) |
Width |
1,336 mm [52-5/8″] |
1,326 mm [52-3/16″] |
| Height |
757 mm [29-13/16″] (with music rest: 939 mm [37-0″]) |
744 mm [29-5/16″] (with music rest: 942 mm [37-1/16″]) |
| Depth |
377 mm [14-13/16″] (with music rest: 402 mm [15-13/16″]) |
318 mm [12-1/2″] (with music rest: 362 mm [14-1/4″]) |
| Dimensions of Packing Box |
W x H x D |
1,457 mm x 311 mm x 531 mm [57-3/8″ x 12-1/4″ x 20-7/8″] |
1,424 mm x 233 mm x 362 mm [56-1/16″ x 9-3/16″ x 14-1/4″] |
| Control Interface |
| Keyboard |
Number of Keys |
88 |
88 |
| Type |
GrandTouch-S™ Keyboard: wooden keys (white only), synthetic ebony and ivory key tops, escapement |
GHC keyboard with matte black keytops |
| Touch Sensitivity |
Hard2/Hard1/Medium/Soft1/Soft2/Fixed |
Hard/Medium/Soft/Fixed |
| Pedal |
Number of Pedals |
3 (when using the pedal unit, LP-1/FC35) |
– |
| Assignable Functions |
Sustain (Switch), Sustain (Continuous), Sostenuto, Soft, Pitch Bend Up, Pitch Bend Down, Rotary Speed, Vibe Rotor, Song Play/Pause |
– |
| Display |
Type |
Full Dots LCD |
– |
| Size |
198 x 100 dots |
– |
| Language |
English, Japanese |
– |
| Panel |
Language |
English |
English |
| Voices |
| Tone Generator |
Piano Sound |
Yamaha CFX, Bösendorfer Imperial |
Yamaha CFX |
| Binaural Sampling |
Yes (“CFX Grand” Voice only) |
– |
| Virtual Resonance Modeling (VRM) |
Yes |
Yes (VRM Lite) |
| Grand Expression Modeling |
Yes |
– |
| Key-off Samples |
– |
Yes |
| Damper Resonance |
– |
– |
| Polyphony (max.) |
256 |
192 |
| Preset |
Number of Voices |
44 Voices + 18 Drum/SFX Kits + 480 XG Voices |
24 |
| Compatibility |
XG (GM), GS (for Song playback), GM2 (for Song playback) |
– |
| Effects |
| Types |
Reverb |
7 types |
4 types |
| Chorus |
3 types |
– |
| Master EQ |
3 Preset + 1 User |
– |
| Insertion Effect |
12 types |
– |
| Intelligent Acoustic Control (IAC) |
Yes |
Yes |
| Stereophonic Optimizer |
Yes |
Yes |
| Sound Boost |
3 types |
2 types |
| Wall EQ |
– |
Yes |
| Functions |
Dual/Layers |
Yes |
Yes |
| Split |
Yes |
Yes |
| Duo |
Yes |
Yes |
| Songs |
| Preset |
Number of Preset Songs |
21 Voice Demo Songs + 50 Classics |
21 Voice Demo Songs + 50 Classics |
| MIDI Recording |
Number of Songs |
250 |
1 |
| Number of Tracks |
16 |
2 |
| Data Capacity |
Approx. 500 KB/Song (approx. 22,000 notes) |
Approx. 100 KB/Song (approx. 11,000 notes) |
| Audio Recording (USB memory) |
Recording Time (max.) |
80 minutes/Song |
– |
| Compatible Data Format |
Playback |
SMF (Format 0, Format 1), WAV (44.1 kHz sample rate, 16-bit resolution, stereo) |
– |
| Recording |
SMF (Format 0), WAV (44.1 kHz sample rate, 16-bit resolution, stereo) |
– |
| Functions |
| Piano Room |
Yes |
– |
| Rhythm |
Number of Rhythms |
40 |
20 |
| Registration Memory |
Number of Buttons |
6 (x 4 banks) |
– |
| Overall Controls |
Metronome |
Yes |
Yes |
| Tempo Range |
5 – 500 |
5 – 280 |
| Transpose |
-12 – 0 – +12 |
-6 – 0 – + 6 |
| Tuning |
414.8 – 440.0 – 466.8 Hz (approx. 0.2 Hz increments) |
414.8 – 440.0 – 466.8 Hz (approx. 0.2 Hz increments) |
| Scale Type |
7 types |
– |
| USB Audio Interface |
44.1 kHz, 24 bit, stereo |
44.1 kHz, 24 bit, stereo |
| Bluetooth |
Audio/MIDI (varies by area) |
Audio (varies by area) |
| Storage and Connectivity |
| Storage |
Internal Memory |
Total maximum size approx. 1.4 MB |
– |
| External Drives |
USB flash drive |
– |
| Connectivity |
Headphones |
Standard stereo phone jack (x 2) |
Standard stereo phone jack (x 2) |
| MIDI |
IN, OUT |
– |
| AUX IN |
Stereo mini jack |
– |
| AUX OUT |
Standard phone jack (L/L+R, R) |
[L/L+R] [R] |
| USB TO DEVICE |
Type A |
– |
| USB TO HOST |
Type C |
Yes |
| DC IN |
16 V |
12 V |
| Sustain Pedal |
Yes (assignable) |
Yes |
| Pedal Unit |
Yes |
Yes |
| Amplifiers and Speakers |
| Amplifiers |
(20 W + 6 W) x 2 |
7 W x 2 |
| Speakers |
(Oval (12 cm x 6 cm) + 2.5 cm (dome)) x 2 |
(Oval (12 cm x 8 cm) + 5 cm) x 2 |
| Power Supply |
| AC Adaptor |
PA-300C (Output: DC 16 V, 2.4 A) |
PA-150B or an equivalent recommended by Yamaha (Output: DC 12 V, 1.5 A) |
| Power Consumption |
18 W (when using PA-300C AC adaptor) |
9 W (When using PA-150B AC adaptor) |
| Accessories |
| Included Accessories |
Owner’s Manual, Online Member Product Registration, Music rest, Foot pedal (FC3A), Power cord*/AC adaptor* (PA-300C) *Varies by area |
Owner’s Manual, Online Member Product Registration, Music rest, Footswitch, AC adaptor* (PA-150B or an equivalent recommended by Yamaha) *Varies by area |
| Separately Sold Accessories |
Headphones (HPH-150, HPH-100, HPH-50), Keyboard stand (L-515), Pedal unit (LP-1, FC35), Foot pedal (FC3A), Footswitches (FC4A, FC5), AC adaptor* (PA-300C), USB wireless LAN adaptor (UD-WL01) *Varies by area |
Headphones (HPH-150, HPH-100, HPH-50), Keyboard stand (L-200), Pedal unit (LP-1, FC35), Foot pedal (FC3A), Footswitch (FC4A, FC5), Keyboard bag (SC-KB851), AC adaptor* (PA-150B or an equivalent recommended by Yamaha), Wireless MIDI adaptor (UD-BT01) *Varies by area |
